Module Categories: Input Module

Gorillacell Module 036: Analog Touch Sensor

The Analog Touch Sensor is a capacitive touch sensor that changes its capacitance when touched. This variation in capacitance is converted into an analog signal, allowing the sensor to detect different touch levels or positions. The Gorillacell ESP32 Development Kit includes one Analog Touch Sensor module featuring four unique touch inputs on a single analog pin. Each touch area produces a distinct analog value, enabling multiple touch detections using only one input pin.

Read more Gorillacell Module 036: Analog Touch Sensor

Gorillacell Module 034: Joystick

The Joystick is essentially composed of two potentiometers arranged perpendicularly to detect horizontal (X-axis) and vertical (Y-axis) movements. By varying the resistance in each axis, it provides analog input signals corresponding to the direction and magnitude of movement. It is commonly used in game controllers, robotics, and control interfaces. The Gorillacell ESP32 Development Kit includes one Joystick module for experimenting with directional input control and analog movement detection.

Read more Gorillacell Module 034: Joystick

Gorillacell Module 033: Slider Potentiometer

The Slider Potentiometer is another type of potentiometer, designed in a linear slider form factor instead of a rotary knob. It adjusts resistance by moving the slider along a straight path, making it ideal for applications that require precise linear control, such as audio mixers or user input interfaces. The Gorillacell ESP32 Development Kit includes one Slider Potentiometer module for experimenting with analog input control and smooth variable adjustments.

Read more Gorillacell Module 033: Slider Potentiometer

Gorillacell Module 032: Continuous Rotation Potentiometer

The Infinite Rotation Potentiometer, also known as a Continuous Rotation Potentiometer, is a type of potentiometer that has no mechanical stoppers at either its minimum or maximum positions. As the knob is rotated toward the maximum position, the resistance increases accordingly. Once it reaches the end of its range, a further rotation causes the resistance to wrap around back to the minimum value, and vice versa. This allows continuous, smooth adjustment without physical limits.

Read more Gorillacell Module 032: Continuous Rotation Potentiometer

Gorillacell Module 031: Potentiometer

The Potentiometer is an input device that varies its resistance when the knob is rotated. It is commonly used for adjusting voltage levels, controlling brightness, or tuning input values in electronic circuits. The Gorillacell ESP32 Development Kit includes one Potentiometer module. It features mechanical stoppers at its minimum and maximum positions to prevent over-rotation and ensure durability during use.

Read more Gorillacell Module 031: Potentiometer
