Gorillacell Module 030: Weight Sensor

The Weight Sensor measures the weight of an object. It consists of a weighing platform containing a load cell, which changes its electrical resistance when a force is applied, and the platform itself. The sensor is paired with a driver board that uses the HX711 24-bit Analog-to-Digital Converter (ADC). The HX711 amplifies and converts the analog signal from the load cell into a digital signal that can be processed by a microcontroller. The module communicates with the microcontroller via a Serial I²C protocol, making it easy to interface with devices like the ESP32.

Read more Gorillacell Module 030: Weight Sensor

Gorillacell Module 029: Rotary Encoder

The Rotary Encoder detects rotational movement and its direction using two out-of-phase signals. Some rotary encoders also include an integrated push button switch, which is ideal for navigating menu-driven user interfaces or other interactive projects.

Read more Gorillacell Module 029: Rotary Encoder

Gorillacell Module 028: SHT30 Temperature and Humidity Sensor

The Temperature and Humidity Sensor provides accurate measurements of the surrounding temperature and humidity.

Read more Gorillacell Module 028: SHT30 Temperature and Humidity Sensor

Gorillacell Module 027: DHT11 Temperature and Humidity Sensor

The Temperature and Humidity Sensor provides real-time measurements of the surrounding temperature and humidity.

Read more Gorillacell Module 027: DHT11 Temperature and Humidity Sensor

Gorillacell Module 026: Ultrasonic Sensor

The Ultrasonic Sensor measures distance using high-frequency sound waves. The Gorillacell ESP32 Development Kit includes an Ultrasonic Sensor module, driven by the HC-SR04 driver chip, which handles generating and receiving the sound waves. The sensor has two “eyes”: one acts as a transmitter that emits sound waves, and the other serves as a receiver that detects the waves reflected back from an object.

Read more Gorillacell Module 026: Ultrasonic Sensor
